BORNIT® Adhesive Filler

bitumen | filler compound | cartridge | joints | sealing
short information
  • combination product for gluing and sealing
  • crack bridging and strong adhesive
  • precise, economical application from the cartridge
  • exact dosage using a standard cartridge gun
Adhesive Filler
310 ml / cartridge
sufficient for:
EAN code
approx. 12 m
4 017228 00316 0
20 cartridge
  • for filling work approx. 12 m/cartridge at a joint cross-section of 5 x 5 mm.
  • for adhesion work approx. 100 g (or ml, resp.) per running metre (at a width of 4 cm).
storage note
  • not sensitive to frost
  • in originally sealed containers storable for 12 months
  • keep away from sources of ignition!

status technical data sheet
6 March 2023

areas of application
BORNIT® Adhesive Filler is suitable for small-area waterproofing of cracks, holes, hollows, connections and for adhering bituminous vapour barrier sheeting, sanded bituminous sheeting and thermal insulation panels made of polystyrene (laminated and unlaminated) and of polyurethane (with nonwovens, PE/nonwovens lamination) on flat roofs. The material adheres well to mineral substrates (plaster, concrete, masonry), grease-free metal, wood, bituminous sheeting and felts.

type and properties
BORNIT® Adhesive Filler is a plastoelastic bitumen filler compound, especially designed for smaller repairs and quickly processable, directly from the cartridge. The material is resistant to non-oxidising acids, UV radiation and particularly weatherproof. The material is stable and also adheres to vertical surfaces.

  • manufactured ready for use
  • low expenditure on equipment and material and effort, therefore economic and cost-cutting
  • crack-bridging and highly adhesive
  • accurate, economic application right from the cartridge

The substrate must be dry, clean, oil- and grease-free as well as stable. For better adhesion to concrete, masonry or plaster, BORNIT Bitumen Primer should be used as a primer. This primer must have completely dried prior to starting any work. The product contains solvents, which may adversely affect plastics, etc. Therefore, please check compatibility on these substrates prior to processing!

BORNIT® Adhesive Filler is processed using a cartridge press 301 ml. The product is best processable at temperatures above +10 °C. Upon prior storage in warm surroundings, however, processing is possible down to outside temperatures of -5 °C. In that, application thicknesses up to 5 mm are possible.

for filling work approx. 12 m/cartridge at a joint cross-section of 5 x 5 mm.
for adhesion work approx. 100 g (or ml, resp.) per running metre (at a width of 4 cm).

product data in brief
product type
bituminous filler
bitumen, white spirit, aggregates
white spirit
density at +20 °C
1.20 - 1.30 g/cm³
softening point acc. to cone/ring
+170 °C
heat resistance
+70 °C, 2h, no expire
cartridge, spatula
with BORNIT® Bitumen Cleaner, BORNIT® MultiClean Spray or BORNIT® MultiClean
not sensitive to frost
shelf life
in originally sealed containers storable for 12 months keep away from sources of ignition!
GISCODE link comp. A
VOC category
actual permissible VOC content
< 230 g/ l
hazard class according to ADR
entzündbare Flüssigkeiten (Flam. Liq. 3)
Acc. to Industrial Safety Regulation (BetrSichV)
boiling start and Boiling range
> +150 °C
upper/lower explosion limit
6,4 - 0,67 Vol-%
flash point
24,0 °C
flexibility at 4 °C
no cracking
water permeability 0.5 bar, 8 h
bridging crack widths
0,5 - 2,0 mm, clearly fulfilled

health and fire protection, occupational safety
To ensure safe handling of the product, the physical, safety, toxicological and ecological information provided online, the information in the current safety data sheet and the additional information on the label must be read and followed before purchasing or using the product! The applicable regulations, ordinances and laws must be complied with.

In case of doubt, please contact the BORNIT® application technology department or the BORNIT® service hotline on +49 375 2795 123.

Can be stored for 12 months in originally closed cartridges. Not sensitive to frost!

disposal note
Only recycle completely empty containers. Material residues can be disposed of according to AVV-ASN: 080409* (waste adhesives and sealants containing organic solvents or other dangerous substances).

The above information replaces all previous technical information about the product. Thus, this information is no longer valid. The details have been compiled according to the latest state of application technology. Please observe, however, that, depending on the state of the construction object, deviations from the method of application suggested in the datasheet may be required. Unless agreed otherwise in individual contracts, any information contained in the datasheet shall be non-binding and thus does not represent an agreed product constitution. We reserve the right to any changes in the information contained in this datasheet anytime.


Safety Data Sheet Poison Information Centre , 24h: +49-361-730730

ERFURT - Poison Control Centre Erfurt, Joint Poison Information Centre of the federal States of Mecklenburg-Western Pomerania, Saxony, Saxony-Anhalt and Thuringia; ggiz@ggiz-erfurt.de; www.ggiz-erfurt.de

-     What: name of the substance or product as precisely as possible, etc.
-     How much: as exact a quantity as possible
-     Who: Age, weight, sex and condition of the person(s) concerned.
-     When: Time of the event
-     Where: Place of occurrence
-     How: ingestion, inhalation, skin contact, etc.
-     Why: accidentally or intentionally


No dangerous good in sense of these transport regulations.

Hazard pictograms

signal word

Hazard-determining components for labelling
Hydrocarbons, C9-C11, n-alkanes, isoalkanes, cyclics, <2% aromatics

H226: Flammable liquid and vapour.
H336: May cause drowsiness or dizziness.

EUH066: Repeated exposure may cause skin dryness or cracking.

P102: Keep out of reach of children.
P210: Keep away from heat, hot surfaces, sparks, open flames and other ignition sources. No smoking.
P271: Use only outdoors or in a well-ventilated area.
P403 + P233: Store in a well-ventilated place. Keep container tightly closed.
P501: Dispose of contents/container to a suitable recycling or disposal facility.
P280: Wear protective gloves/protective clothing.

recommended, personal protective equipment:
