BORNIT® Hot Sealing PS - BORNIT-Werk Aschenborn
232

BORNIT® Hot Sealing PS

bitumen | road construction | hot sealing compound | joint compound | grout
BORNIT
Short information
  • good absorption of movement
  • good adhesion to the joint flanks
  • insensitive to water and de-icing salts
Product
Colour
Content
Hot Sealing PS
black
15 kg / box
sufficient for:
Order-No.
EAN code
euro pallet
approx. 22.5 litres joint content
6800000422
4 017228 007021
64 box
Hot Sealing PS
black
30 kg / box
sufficient for:
Order-No.
EAN code
euro pallet
approx. 45 litres joint content
6800000421
4 017228 007038
64 box
Consumption
  • approx. 1.5 kg / litre of joint volume
  • consumption of the primer amounts to approx. 4 % of the amount of sealing compound
Storage note
  • protect from direct solar irradiation and moisture
  • in originally sealed containers storable for 24 months

Status technical data sheet
03 December 2020

Areas of application
BORNIT® Hot Sealing PS serves sealing and closing of joints for all kinds of pavements. BORNIT® Hot Sealing PS can also be used for sealing of only slightly loaded joints in structures made of concrete, masonry and reinforced concrete.

Type and properties
BORNIT® Hot Sealing PS is a bitumen-based sealing compound with mineral fillers. The pavement joint compound is a meltable and hot workable sealing compound. It corresponds to the quality requirements according to ZTV Fug-StB 15.

Advantages
  • good absorption of movement
  • good adhesion to the joint flanks
  • insensitive to water and de-icing salts

Surface
The joints must be dry and clean. Residues of oil and grease as well as loose particles must be removed. Cleanly blow out the joints with compressed air.

Processing
Prior to application, the joint flanks must be primed with BORNIT® Hot Compound Primer. The primer must have dried off prior to application of the compound (finger test). First, remove the packaging from the sealing compound. Then slowly heat BORNIT® Hot Sealing PS to the processing temperature in a melting pot equipped with a stirring unit, a thermostat-controlled burner and a thermometer. In that, comply with the maximum melting temperature of +180 °C in any case and keep the compound moving using the stirring unit, in order to avoid local overheating and deposition. Only melt the quantity prospectively required for the day, since the material properties could change with repeated melting. Perform application using suitable equipment (e.g., narrow pouring jugs with elongated spout, etc.). Should it start raining, stop application immediately!
Since there is a reduction in volume after cooling down with all sealing compounds, application should be undertaken in two working steps. In that, the second layer should be applied immediately after cooling down of the first one, onto the still shiny and clean surface. In that, the processing temperature must not be undercut, in order to guarantee homogeneous amalgamation.
BORNIT® Hot Sealing PS must be applied such that a trough-shaped indentation of at least 1 mm to 6 mm, at most (with chamfered joint edges) is formed below the pavement surface. Protrusions or excess material, resp., are to be avoided.

Consumption
approx. 1.5 kg / litre of joint volume
consumption of the primer amounts to approx. 4 % of the amount of sealing compound

Product data in brief
Product type
bituminous sealing joint compound
Base
bitumen
Density at +20 °C
approx. 1.5 g/cm³
Softening point acc. to cone/ring
min. +75 °C
Consistency
pourable after heating
Colour(s)
black
Application
with pouring can
Processing temperature (ambient and substrate)
approx. +150 °C
Cleaning
BORNIT® MultiClean Spray, BORNIT® MultiClean, BORNIT® Bitumen Cleaner
Storage
protect from direct solar irradiation and moisture
Shelf life
in originally sealed containers storable for 24 months
Substances hazardous to health in terms of the ordinance on hazardous materials
none
Hazard class according to ADR
none
Flash point
> +200 °C

Melting temperature
max. +180 °C
Surface temperature of the joint
min. 0°C
Segregation tendency
< 3 Gew. %
Dimensional stability under warm conditions (falling ball test at 120 cm, 0 °C)
3 of 4
Dimensional stability under warm conditions
< 10

Health and fire protection, occupational safety
For information on handling, safety and ecology, please refer to the current safety datasheet.

Storage
The product can be stored for 24 months. The cardboard boxes must be protected from sunlight and moisture!

Disposal note
Only recycle completely empty containers. Material residues can be disposed of according to AVV-ASN: 170302 (bitumen mixtures except for those falling under 170301).

Note
The above information replaces all previous technical information about the product. Thus, this information is no longer valid. The details have been compiled according to the latest state of application technology. Please observe, however, that, depending on the state of the construction object, deviations from the method of application suggested in the datasheet may be required. Unless agreed otherwise in individual contracts, any information contained in the datasheet shall be non-binding and thus does not represent an agreed product constitution. We reserve the right to any changes in the information contained in this datasheet anytime.
BORNIT<sup class=®-Pflastervergussmasse, Pflaster, Fuge, vergießen">
recommended, personal protective equipment:
